Pirn Winder
| Pirn Winder TECHNICAL SPECIFICATION | ||
|---|---|---|
| Model | ATE-SRW | |
| Spindle Max. | 128 (Multiple of 8 Spindle) | |
| Yarn Speed | Max. 800m/min | |
| Pirm Dimension | 42 x 270mm (1kg)/ 42 x 330mm (1.5kg) |
|
| Even Yarn Speed Device | Inverter type | |
| Drive Device | Tangential Flat belt | |
| Spindle Whorve | 32 mm | |
| Travers Device | Timing Belt | |
| Travers Winder | Servomotor control | |
| Optional | Oildevice | |
| No. of Spindle | 48 | 64 | 80 |
96 | 112 | 128 |
| No. of Section | 3 | 4 | 5 | 6 | 7 | 8 |
| Machine length (Mtr.) | 5.76 | 7.20 | 8.64 | 10.08 | 11.52 | 13 |
| Machine width | 750 mm | |||||
Characteristics
- Management of even yarn speed by the free control of winding speed Improvement of quality in yarn by the free control of winding speed
- Improvement by the betterment of yarn guide parts Free selection of traverse distance and yarn speed
- Easy operation of belt and easy stop by use of transparent spindle rail cover-patient application.
Automatic Control system of CNC
- Control of spindle revolution and speed of travers with built-in inverter
- Various memory function of PLC
Spindle & Traverse Drive Part
- Gaurantee of exactness in supplying power by making the contact side of tension pulley round, and prevention of belt from breakaway
